IP CAMERAS
Picture Reference Description
HYU-203

IP bullet camera with IR illumination of 30 meters, for outdoors. 4MP. H.264/H.264+/MJPEG. 1/3" CMOS, 4MP. 4MP /1080P /720P /CIF. mechanical filter. 0,014 lux. 2,8~12 mm motorized lens (112°~33,8°). OSD, 3D-NR, BLC, real WDR (120 dB), privacy mask, ROI. Intelligent functions (IVS). MicroSD//SDHC/SDXC. IP67. 12V DC. PoE.

HYU-240 IP bullet camera with IR illumination of 30 meters, for outdoors, 2MP. H.264/MJPEG. 1/3" CMOS, 2MP. 1080P /1,2MP /720P. mechanical filter. 0.014 lux. 2.8~12 mm varifocal lens (113º~33.8º). OSD, 3D-NR, BLC, digital WDR, privacy mask, ROI zones. Intelligent functions. MicroSD/SDHC/SDXC. IP67. 12V DC. PoE
HYU-396 Fixed IP vandal dome, IR illumination of 30m, for outdoors, 8 MP. H.265+ /H.265 /H.264+ /H.264 /MJPEG. 1/2,5" CMOS, 8MP. Triple stream. Mechanical filter. 0,014 lux. 2,8 ~12 mm motorized lens (115°~35°). OSD, 3D-NR, BLC, real WDR 120dB, motion detection, privacy mask, 1 ROI. IVS. Audio: 1 in / 1 out. Alarm: 1 in / 1 out. MicroSD/SDHC/SDXC. IP67, IK10, Lightning-proof 2KV. 12V DC. PoE.
HYU-397 Fixed IP vandal dome with IR illumination of 30 m., for outdoor, 8 MP. H.265+ /H.265 /H.264+ /H.264 /MJPEG. 1/2,5" CMOS, 8MP. Triple stream. Mechanical filter. 0,014 lux. 2,8 ~12 mm motorized lens (115°~35°). OSD, 3D-NR, BLC, real WDR 120dB, motion detection, privacy mask, 1 ROI. IVS. Audio: 1 in / 1 out. Alarm: 1 in / 1 out. MicroSD/SDHC/SDXC. IP67, IK10, Lightning-proof 2KV. 12V DC. PoE.
HYU-241 IP fixed vandal dome with IR illumination of 30 meters, for outdoors, 2MP. H.264/MJPEG. 1/3" CMOS, 2MP. 1080p/1.2MP/720p. Mechanical filter. 0.014 lux. 2.8~12 mm varifocal lens (113º~33.8º). OSD, 3D-NR, BLC, digital WDR, privacy mask, ROI, Intelligent functions (IVS). MicroSD/SDHC/SDXC. IP67, IK10. 3AXIS. 12V DC. PoE
HYU-313 Fixed IP dome with IR illumination of 20~30m, for outdoors, 4 MP. H.264/H.264+/MJPEG. 1/3" CMOS, 4MP. Digital resolution: 4MP, 3MP, 1080P, 720P, etc. Mechanical filter. 0,01 lux. 2,8~12 mm motorized lens (98°~30°) with autofocus. OSD, AGC, BLC, real WDR 120dB, 3D-DNR, motion detection, privacy mask, fixed ROI zones. IP67. 3AXIS. 12V DC. PoE.
HYU-314 Fixed IP dome with IR illumination of 20~30m, for outdoors, 2MP. H.264/H.264+/MJPEG. 1/2,8" CMOS, 2MP. Digital resolution: 1080P, 1,3MP, 720P, etc. Mechanical filter. 0,01 lux. 2,8~12 mm motorized lens (90°~35°) with autofocus. OSD, AGC, BLC, real WDR 120dB, 3D-DNR, motion detection, privacy mask, fixed ROI zone. IP67. 3AXIS. 12V DC. PoE.
ANALOG TURBO HD CAMERAS
Picture Reference Description
HYU-435 HD-TVI TURBO HD 4.0 bullet camera ULTRAPRO series with IR illumination of 80 m, for outdoors. 8,3MP CMOS. HD-TVI/CVBS double video output. 2,8~12 mm motorized lens (108,1°~45,6°) with autofocus. ICR filter. OSD, ATW, MWB, AGC, BLC, HLC, real WDR 120dB, 3D-DNR, defog, mirror, privacy mask. IP67. 3AXIS. 12V DC.
HYU-436 HD-TVI TURBO HD 4.0 fixed dome ULTRAPRO series with IR illumination of 80 m for outdoors. 8,3MP CMOS. Double video output HD-TVI/CVBS. 2,8~12 mm motorized lens (108,1°~45,6°) with autofocus. ICR. OSD, ATW, MWB, AGC, BLC, HLC, real WDR 120dB, 3D-DNR, defog, mirror, privacy mask. IP67. 3AXIS. 12V DC.
HYU-437 HD-TVI TURBO HD 4.0 bullet camera ULTRAPRO series with IR illumination of 40 m for outdoors. 8,3MP CMOS. Double video output HD-TVI/CVBS. 2,8 mm fixed lens (102,2°). ICR filter. OSD, ATW, MWB, AGC, BLC, HLC, real WDR 120dB, 3D-DNR, defog, mirror, privacy mask. IP67. 3AXIS bracket. 12V DC.
HYU-438 HD-TVI TURBO HD 4.0 fixed dome ULTRAPRO series with IR illumination of 60 m, for outdoors. 8,3MP CMOS. Double video output HD-TVI/CVBS. 2,8 mm fixed lens (102,2°). ICR filter. OSD, ATW, MWB, AGC, BLC, HLC, real WDR 120dB, 3D-DNR, defog, mirror, privacy mask. IP67. 3AXIS. 12V DC
IP NVR
Picture Reference Description
HYU-206 4 channel IP NVR. H.264+. 4 ch @ 1080p synchronous display. 6MP display. Recording: 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1/4CIF, etc. 40 Mbps. VGA and HDMI output @ 1080p. Two-way audio. 1HDD SATA. Onvif, P2P, DDNS, 12V DC. 1U.
5 IN1 ANALOG TURBO HD DVR
Picture Reference Description
HYU-231 16 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channels 4MP. H.264+/H264. Audio: 4 in / 1 out (2 way audio). Resolution per channel: 3 Mpx (12FPS) or 1080p, 1080PLite/720P (25FPS). BNC output at D1/4CIF. HDMI and VGA output at 1080P. Alarm: 16 in / 4 out. 2 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 1 USB 2.0, 1 USB 3.0, 1 RS485. 12V DC
HYU-322 8 channel 5in1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channels. H.264+/H264. 2 way audio. 8 channel @ 1080P. 3MP recording (channels 1 and 2,, 15 fps, only TVI), 1080P, 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF, full 1080N in all cameras or 12 fps 1080P. BNC output at D1/4CIF. HDMI @ 4K and VGA @ 2560x1440. Alarm: 8 in / 1 out. 1 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC
HYU-323 16 channel 5in1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channels. H.264+/H264. 2 way audio. 16 channel @ 1080P. 3MP recording (channels 1 to 4, 15 fps, only TVI), 1080P, 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF, full 1080N in all cameras or 12 fps 1080P. BNC output at D1/4CIF. HDMI @ 4K and VGA @ 2560x1440. Alarm: 16 in / 1 out. 1 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC
HYU-370 4 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 1 IP channel. H.265+/H265/H.264+/H264. 2 way audio. 4 channel playback at 1080P. Recording: 4M-N, 3MP (channel1, 15 fps, only TVI), 4MP (1 IP input), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF (25 fps). BNC output at D1/4CIF. HDMI and VGA output at 1080P. 1 HDD SATA. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC.
HYU-371 8 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channel. H.265+/H265/H.264+/H264. 2 way audio. 8 channel playback at 1080P. Recording: 4M-N, 3MP (channel1 & 2, 15 fps, only TVI), 4MP (2 IP input), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF (25 fps). BNC output at D1/4CIF. HDMI and VGA output at 1080P. 1 HDD SATA. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC.
HYU-372 16 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channel. H.265+/H265/H.264+/H264. 2 way audio. 16 channel playback at 1080P. Recording: 4M-N, 3MP (channels 1 to 4, 15 fps, only TVI), 4MP (2 IP inputs), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF (25 fps). BNC output at D1/4CIF. HDMI output at 4K and VGA at 1080P. 1 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC.
HYU-373 4 channel 5 in 1 ZVR, HDCVI/HDTVI/AHD/CVBS + 1 IP channel. H.265+/H265/H.264+/H264. 2 way audio. 4 channel playback at 1080P. Recording: 4M-N, 3MP (channel 1, 15 fps, only TVI), 4MP (1 IP input), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF, QVGA, QCIF (25 fps). BNC output at D1/4CIF. HDMI and VGA output at 1080P. Alarm: 4 in / 1 out. 1 HDD SATA capacity. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC.
HYU-376 4 channel 5 in 1 ZVR 5 MP (12 fps) / 4 MP (15 fps) / 3MP (18 fps) / 1080P (25 fps) HDTVI/HDCVI/AHD/CVBS + 2 IP channels 6MP. H.265+/H.265/H.264+/H.264. Audio: 4 in / 1 out (2 way audio). Recording: 6MP (IP), 5MP/4MP/3MP (TVI), 1080P, 720P, WD1, 4CIF, VGA, CIF, QVGA, QCIF, full 1080P in all cameras. BNC output at 4CIF. HDMI and VGA output at 1080P. Alarm: 4 in / 1 out. 1 HDD SATA capacity. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC
HYU-377 8 channel 5 in 1 ZVR 8MP (7 ips) / 5 MP (12 fps) / 4 MP (15 fps) / 3MP (18 fps) / 1080P (25 fps) HDTVI/HDCVI/AHD/CVBS + 2 IP channels 6MP. H.265+/H.265/H.264+/H.264. Audio: 4 in / 1 out (2 way audio). Recording: 6MP (IP), 8MP/5MP/4MP/3MP (TVI), 1080P, 720P, WD1, 4CIF, VGA, CIF, QVGA, QCIF, full 1080P in all cameras. BNC output at 4CIF. HDMI (4K, 2K) and VGA (1080P) output. Alarm: 8 in / 4 out. 1 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 2 USB, 1 RS485. 12V DC
HYU-379 4 channel 5 in 1 TURBO HD 4.0 ZVR, 8MP (10FPS) / 5MP (20FPS) / 4MP (25FPS) / 3MP (18FPS) / 1080P (25FPS) HDCVI/HDTVI/AHD/CVBS + 2 IP channels at 8MP. H.265+/H.265/H.264+/H264. Audio: 4 in / 1 out (2 way audio). Recording 8MP/5MP/4MP/3MP (TVI), 1080P/720P (CVI, AHD), WD1/4CIF/VGA/CIF (CVBS), full 4MP in all cameras. BNC a@ 4CIF output. HDMI (4K, 2K) and VGA (1080P) output. Alarm: 4 in / 1 out. 1 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 1 USB 2.0. 1 USB 3.0, 1 RS485. 12V DC.
HYU-380 8 channel 5 in 1 TURBO HD 4.0 ZVR 8MP (10FPS) / 5MP (20FPS) / 4MP (25FPS) / 3MP (18FPS) / 1080P (25FPS) HDCVI/HDTVI/AHD/CVBS + 2 IP channel up to 8MP. H.265+/H.265/H.264+/H264. Audio: 8 in / 1 out (2 way audio). Recording: 8MP/5MP/4MP/3MP (TVI), 1080P/720P (CVI, AHD), WD1/4CIF/VGA/CIF (CVBS), full 4MP in all cameras. BNC output @ 4CIF. HDMI (4K, 2K) and VGA (1080P) output. Alarm: 8 in / 1 out. 2 HDD SATA capacity. RJ45 Gigabit. Onvif, P2P, DDNS. 1 USB 2.0. 1 USB 3.0, 1 RS485. 12V DC.
HYU-383 4 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 1 IP channels. H.265+/H265/H.264+/H264. 2 way audio. 4 channel playback 1080P. Recording 4 MP (1 IP input) 4M-N, 3MP (channel 1, 15 fps, only TVI), 4MP (2 IP inputs), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF (25 fps). HDMI and VGA at 1080P. 1 HDD SATA capacity. Onvif, P2P, DDNS. 2 USB. 12V DC
HYU-384 8 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channels. H.265+/H265/H.264+/H264. 2 way audio. 8 channel playback 1080P. Recording 4 MP (2 IP input) 4M-N, 3MP (channel 1 and 2, 15 fps, only TVI), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF (25 fps). HDMI and VGA at 1080P. 1 HDD SATA capacity. Onvif, P2P, DDNS. 2 USB. 12V DC
HYU-385 16 channel 5 in 1 ZVR HDCVI/HDTVI/AHD/CVBS + 2 IP channels. H.265+/H265/H.264+/H264. 2 way audio. 16 channel playback. Recording: 4MP (2 IP inputs), 4M-N, 3MP (channel 1 to 4, 15 fps, only TVI), 1080P (15 fps), 1080N, 720P, 960H, D1/4CIF, VGA, CIF (25 fps). HDMI and VGA output at 1080P. 1 HDD SATA capacity. Onvif, P2P, DDNS. 2 USB. 12V DC.
Ask your sales representative for more information and discounts
